380V Steel Metal Filter Housing Surface Automatic Grinding And Polishing Machine
| Place of Origin | China |
|---|---|
| Brand Name | Trancar Industries |
| Certification | CE/ISO |
| Model Number | TCM-NP |
| Minimum Order Quantity | 1 set |
| Price | USD 9000-25000 Dollar per set |
| Packaging Details | Custom design plywood box |
| Delivery Time | 35 work days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability | 25 sets per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Steel Metal Filter Housing Surface Automatic Polishing Machine | Dimension | 3500x1600x3050mm |
|---|---|---|---|
| Weight | 2500kg | Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V Etc | Usage | Steel Filter Surface Polishing Grinding |
| Warranty | 18 Month | Provide | ODM & OEM |
| Highlight | 380V Automatic Grinding And Polishing Machine,400V Automatic Grinding And Polishing Machine,415V automatic grinding machine |
||
Product Description
380V Steel Metal Filter Housing Surface Automatic Grinding And Polishing Machine
Product Specifications
| Product Name | Steel Metal Filter Housing Surface Automatic Polishing Machine |
|---|---|
| Dimension | 3500x1600x3050mm |
| Weight | 2500kg |
| Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V etc |
| Usage | Steel filter surface polishing grinding |
| Warranty | 18 Month |
| Provide | ODM & OEM |
Product Description
The Steel Metal Filter Housing Surface Automatic Polishing Machine from Trancar Industries is designed for precision grinding and polishing of small diameter steel pipes, filter housing inner and outer surfaces, as well as steel tanks, pressure vessels, and industrial containers.
Key Applications
- Medical equipment manufacturing
- Chemical and environmental purification systems
- Food, beverage, and water filtration systems
- Various steel metal cylinder tanks including atmospheric/pressure tanks, CIP tanks, and fermentation tanks
- Pharmaceutical mixers and bio/cosmetics reactors
- Centrifugal cylinder shells and crystal furnace tank shells
Technical Parameters
| Steel Tank Size | Outside diameter: 400~5000mm / 7000 mm Inside diameter: 400~5000mm / 7000 mm Length: ≤5000mm / 8000 mm |
|---|---|
| Tank Roller Capacity | 1 Ton, 2 Ton, 5 Ton, 10 Ton options available Customization up to 13T, 15T, 20T |
| Polishing Precision | Surface roughness (Ra) ≤0.25μm |
| Production Efficiency | Polishing working speed: 6~12 m²/h |
| Machine Dimension | 3500*1600*3080mm |
| Column Dimension | 300x400x8 mm |
| Beam Dimension | 150x200x6 mm |
| Input Power | 12 kw |
| Power Supply | 380V 415V / 50Hz 60HZ / 3p or Customization |
| Machine Weight | 2250kg |
| Color Options | Grey/Green/Blue/Red/Yellow or custom design |
| Suitable Polishing Materials | Abrasive sanding belts, grinding wheels (flap/cloth/emery/Nylon wheel etc) |
Custom Automation Solutions
Trancar Industries provides customized polishing solutions for steel filter housings and industrial containers. Our team of engineers can design machines to meet your specific production requirements and surface finish standards.
