Steel Sheet Longitudinal Welding Seam Crushing Machine PLC Automatic Welding Planisher
| Place of Origin | China |
|---|---|
| Brand Name | Trancar Industries |
| Certification | CE/ISO |
| Model Number | TCM-LP |
| Minimum Order Quantity | 1 set |
| Price | USD 20000-60000 Dollar per set |
| Packaging Details | Standard Export Package |
| Delivery Time | 50 work days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability | 10 sets per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Steel Sheet Longitudinal Welding Seam Crushing Machine PLC Automatic Welding Line Planisher | Dimension | 5800x900x1800 Mm |
|---|---|---|---|
| Weight | 4500 Kg | Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V Etc | Usage | Steel Sheet Surface Longitudinal Welds Crushing & Planishing |
| Condition | 100% New | Warranty | 1 Year |
| Provide | ODM & OEM | Control System | PLC Program |
| Highlight | PLC welding planisher,Automatic welding planisher,Longitudinal planishing welds |
||
Product Description
Steel Sheet Longitudinal Welding Seam Crushing Machine PLC Automatic Welding Planisher
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | Steel sheet longitudinal welding seam crushing machine PLC automatic welding line planisher |
| Dimension | 5800x900x1800 mm |
| Weight | 4500 kg |
| Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V etc |
| Usage | Steel sheet surface longitudinal welds crushing & planishing |
| Condition | 100% new |
| Warranty | 1 year |
| Provide | ODM & OEM |
| Control System | PLC program |
Product Description
The TCM-LP automatic welding seam planishing machine is designed for steel sheet surface treatment, specifically for flattening, crushing, and planishing longitudinal welded seams before polishing. This machine ensures higher quality stainless steel tanks by improving surface finish and is widely used in pharmaceutical, chemical, environmental purification, food & beverage, and water filtration industries.
Technical Parameters
| Steel metal tank size | Tank shell diameter ≧ 1000 mm |
| Tank / Welded Seam Length Max. | 4000 mm / 5000mm (Custom design available) |
| Tank shell Max.Weight | 1 Ton / 2 Ton / 5 Ton /10 Ton |
| Flatten Roller Move Speed | 0.05~2m/min |
| Welded Seam Width | 50-70mm (Based on demands) |
| Flatten machine size | 5800*900*1800mm |
| Operating pressure | 21 Mpa |
| Input total Power | 28 kw |
| Power Supply | 380V 415V / 50Hz 60HZ / 3p or Customization |
| Machine Weight | 4500kg |
| Color | Grey/Green/Blue/Red/Yellow (Custom design available) |
Packaging & Delivery
Custom design service available: Contact Trancar Industries for specialized welds planishing machine solutions tailored to your specific requirements.
