Longitudinal Welding Seam PLC CE Automatic Grinding And Polishing Machine
| Place of Origin | China |
|---|---|
| Brand Name | Trancar Industries |
| Certification | CE/ISO |
| Model Number | TCM-LP |
| Minimum Order Quantity | 1 set |
| Price | USD 20000-60000 Dollar per set |
| Packaging Details | Standard Export Package |
| Delivery Time | 50 work days |
| Payment Terms | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability | 10 sets per Month |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Product Name | Longitudinal Welding Seam PLC Automatic Polishing Grinding Machine | Dimension | 5800x900x1800 Mm |
|---|---|---|---|
| Weight | 4500 Kg | Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V Etc | Usage | Longitudinal Welds Polishing Grinding |
| Condition | 100% New | Warranty | 1 Year |
| Provide | ODM & OEM | Control System | PLC Program |
| Highlight | PLC Welding Line Grinding Polishing Machine,CE Welding Line Grinding Polishing Machine,Longitudinal automatic grinding and polishing machine |
||
Product Description
Longitudinal Welding Seam PLC CE Automatic Grinding And Polishing Machine
Product Specifications
| Attribute | Value |
|---|---|
| Product Name | Longitudinal welding seam PLC automatic polishing grinding machine |
| Dimension | 5800x900x1800 mm |
| Weight | 4500 kg |
| Color | Blue/Red/Grey |
| Voltage | 380V 400V 415V etc |
| Usage | Longitudinal welds polishing grinding |
| Condition | 100% new |
| Warranty | 1 year |
| Provide | ODM & OEM |
| Control System | PLC program |
Product Description
The TCM-LP automatic welding seam polishing grinding machine is designed for steel sheet surface longitudinal welded seams surface treatment, polishing, and grinding. This industrial-grade machine is also capable of processing steel tank shell surface long welding seams, improving surface quality for higher grade stainless steel tanks.
Primary Application: Removing steel tank longitudinal welded seams and lines. Widely used in pharmaceutical, chemical, environmental purification, food & beverage, and water filtration industries.
Technical Parameters
| Steel metal tank size | Tank shell diameter ≧ 1000 mm |
| Tank/Welded Seam Length Max. | 4000 mm / 5000mm (Custom design available) |
| Tank shell Max.Weight | 1 Ton / 2 Ton / 5 Ton /10 Ton |
| Flatten Roller Move Speed | 0.05~2m/min |
| Welded Seam Width | 50-70mm (Customizable based on demands) |
| Flatten machine size | 5800*900*1800mm |
| Operating pressure | 21 Mpa |
| Input total Power | 28 kw |
| Power Supply | 380V 415V / 50Hz 60HZ / 3p (Customizable) |
| Machine Weight | 4500kg |
| Color | Grey/Green/Blue/Red/Yellow (Custom design available) |
Packaging & Delivery
Custom design services available: Contact Trancar Industries for specialized welding seam removal machines and tailored industrial solutions.
