Steel single tube pipe internal side automatic polishing machine

  • Steel single tube pipe internal side automatic polishing machine
  • Steel single tube pipe internal side automatic polishing machine
  • Steel single tube pipe internal side automatic polishing machine
  • Steel single tube pipe internal side automatic polishing machine
  • Steel single tube pipe internal side automatic polishing machine
  • Steel single tube pipe internal side automatic polishing machine
Place of Origin Hefei China
Brand Name TCM
Certification CE
Model Number TCM-NP
Minimum Order Quantity 1 set
Price USD 9000-25000 Dollar per set
Packaging Details Customs design plywood boxes
Delivery Time 20-45 days
Payment Terms L/C, D/A, D/P, T/T, Western Union
Supply Ability 10 sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Name Steel Single Tube Pipe Inside Polishing Machine Voltage 380V/400v/415v Etc
Dimension 15500x3000x1450 Mm Weight 2000 Kg
Core Component PLC Certificate CE
Warranty 1 Year After-sale Service Provide Engineer Oversea Available
Color Grey/Yellow/Red/White Etc Polishing Length Max.6.1m
Leave a Message
Product Description
Steel Single Tube Pipe Internal Side Automatic Polishing Machine
Product Specifications
Attribute Value
Name Steel single tube pipe inside polishing machine
Voltage 380V/400V/415V etc
Dimension 15500×3000×1450 mm
Weight 2000 kg
Core Component PLC
Certificate CE
Warranty 1 year
After-sale Service Engineer oversea available
Color Grey/Yellow/Red/White etc
Polishing Length Max. 6.1m
Precision Internal Surface Polishing Solution
The TCM-NP series mechanical polishing machine provides an efficient solution for achieving precise internal surface roughness (Ra <0.4-0.8μm) on stainless steel and metal tubes. This PLC-controlled automatic system is ideal for applications requiring high-quality mirror finishes on internal pipe surfaces.
Steel single tube pipe internal side automatic polishing machine 0
Key Applications
  • Semiconductor tubes
  • Sanitary stainless steel tubes
  • Industrial water supply and drainage pipes
  • Medical equipment stainless steel pipes
  • Automobile exhaust pipes
  • Heat exchanger pipes
  • Filter tubes
  • Commercial exhibition stainless steel tubes
Technical Specifications
Pipe Diameter Range 76-219mm (Custom designs available for 25.4-306mm)
Maximum Length Capacity 6m, 6.1m, 7m, 8m options
Surface Roughness (Ra) ≤ 0.8-1.6 μm
Machine Weight 2000 KG
Dimensions (L×W×H) 15500×3000×1450 mm
Total Power Input 27 KW
Power Supply 380V/415V, 50Hz/60Hz, 3p (Customizable)
Production Efficiency 60-120 pieces/Hour
Polishing Components Custom design grinding wheels/Sanding belts wheel
Steel single tube pipe internal side automatic polishing machine 1
Custom Design Service Available
Our engineering team can customize the polishing machine to meet specific requirements for tube diameter, length, and surface finish specifications. Contact us for tailored solutions to your precision polishing needs.
